Parameter -Polyurea waterproof coating high pressure spray foam machine
| Item | Polyurethane spray machine. |
Standard configuration | Proportion Fixed Mainframe: 1 set |
| Self-cleaning spray gun: 1 set | |
| Feeding pump: 2 sets | |
| Heating hose: 49.2 feet (15m) | |
| Connecting hose from feeding pump to machine: 10 feet(3m) | |
| Connecting hose from heating hose to gun: 5 feet(1.5m) | |
| Rings and Tools | |
| Technical Data | The ratio of raw material: 1:1(Fixed) |
| The viscosity range of raw material: 200-1000CPS (Under the operate temperature) | |
| Max Working pressure: 25 MPa (200 bar) | |
| Max fluid temperature: 88°C (190°F) | |
| Max Output: 14kg/min (30 lb/min) | |
| Heating hose power: 2000W*2 | |
| Max hose length: 94m (308 feet) | |
| Whole power: 17KW | |
| Voltage: 380V/400V 3-ph | |
| Operate temperature: 0°C-70°C | |
| Clean mode Self-clean by air | |
| Max heating hose length: 308 feet (94m) | |
| Working fluid pressure: 6-8Mpa | |
| Machine size: 1400mm*990mm*60mm | |
| Gross weight: 240KG |
Features -Polyurea waterproof coating high pressure spray foam machine
1. The machine has a small size, light weight, low failure rate, simple operation, easy to move and so on.
2. Use the most advanced pneumatic booster devices, the maximum degree to ensure stability of equipment work.
3. Multiple raw material filter device to minimize the spray plug problem.
4. Multiple leakage protection system to protect the safety of the operator.
5. With an emergency switch system, to the most rapid response to emergencies.
6. Reliable and powerful heating system can make the raw material rapidly heating to the ideal state, to meet the normal construction of equipment.
7. The feeding volume can be adjusted, and has a regular, quantitative function, especially suitable for high-precision small batch of polyurethane casting to improve production efficiency.
8. The latest no-clean spray gun with small size, light weight, low failure rate.
9. Material taken pump use large ratio method, automatic mention material, high viscosity of winter raw materials can also easily feed.
Hydraulic polyurea foam spray machine spray: the construction of the external walls of spraying, spraying products, cold storage spray, refrigerated trucks spraying, roof spraying, industrial anti-corrosion, cabin, carriages, cars, tanks.
hydraulic pressure polyurea and polyurethane insulation spray machine, hydraulic pressure polyurea and polyurethane insulation spray machine
Hydraulic polyurea foam spray machine casting: solar water heaters, insulation tanks, refrigerators, security doors, cabin, insulation boards, pipe joints, product packaging, road construction, wall noise.
1. 24 hours on line service, support Chinese, English, Spanish, French, German, Russian ,technical guidance.
2. When meets machine failure problem, our factory will ensure that the problem is solved within 1 hour.
3. Povide machine install video.
4. Provide logistics information, like shipping by sea, shipping by express DHL, FEDEX delivery, real-time tracking service.
5. If machine is broken ,Non-human causes,the new machine will be provided or new parts will be provided.
SHANDONG HIGHTOP MACHINERY Co., Ltd, established in 1980, is an important and a large construction engineering equipment joint-stock enterprise group. It has several wholly-owned subsidiaries, company headquarters is located at National High Tech Zone, Jining City, Shandong province.
Group's manufacturing area is compromised of 5000 square meters where 2000 people are employed full-timely. Its service scope covers critical economic fields such as construction engineering equipment, mining machinery, rock drilling equipment, steel etc.
CNMC Group got ISO9001 international quality system certification, European Union CE certification,SGS certification and Russian GOST certification. Scientific innovation is CNMC motive power. At 2000 year Our company and China Science and Technology University together established a steel products Rally testing laboratories, strive to enhance the product's impact resistance, in 2002 year the company and Shanghai Institute of Chemical Research jointly established experimental research center for the Chemical Material. Through exchanges and learn, CNMC mechanical, products in the stability of performance has been greatly improved.
More than 30 years of hard work and struggle, CNMC products have been exported to more than 127countries, and win good reputation from our customers, because we always pursue "CNMC FOCUS ONQUALITY" and explored a sustainable development path which combining the economic benefits and environmental protection together, and this make a great contribution to the development of Chinese machinery manufacturing industry and prosperity.
